RM-455W-166M/144

Name: RM-455W-166M/144
Brand: Ronma Solar
SKU: 57029
Price: 0.15000 USD
Availability: OutOfStock

Zhejiang Ronma Solar Group Co,.Ltd.

가격:

최저가격 ₩208 / Wp

유형:	PERC
공율범위:	Wp
지역:	중국

제조업체에 문의

제품은 더 이상 제조되지 않는다.

제품 설명:

1.Excellent PID resistance

2.Power ranges from 430 to 455 watts and up to 20.96% efficiency

3.0-+5W positive tolerance - to ensure high output

4.Dual stage 100% EL Inspection warranting defect-free product.

5.Certificate with CEC/TUV/BIS/CCC/CQC/CE/IEC etc.

제품 정보
회사 프로필

제품특성

모델명

RM-430W-166M/144

RM-435W-166M/144

RM-440W-166M/144

RM-445W-166M/144

RM-450W-166M/144

RM-455W-166M/144

보증

제품보증연한

10 년

출력 보증

25년 동안 84.8% 이상의 효율

전기적 특성 (STC)

최대출력(Pmax)

430 Wp

435 Wp

440 Wp

445 Wp

450 Wp

455 Wp

최대전압(Vmpp)

40.3 V

40.5 V

40.7 V

40.8 V

41 V

41.2 V

최대전류(Impp)

10.67 A

10.74 A

10.82 A

10.9 A

10.98 A

11.06 A

개방전압(Voc)

48.7 V

49 V

49.2 V

49.4 V

49.6 V

49.8 V

단락전류(Isc)

11.23 A

11.31 A

11.39 A

11.46 A

11.53 A

11.61 A

모듈 호률

19.78 %

20.01 %

20.26 %

20.46 %

20.71 %

20.96 %

표준 테스트 조건(STC): AM 1.5, 방사조도 1000W/m², 셀오돈 25°C

전기적 특성 (NOCT)

온도

44±2 °C

공칭 작동 셀 온도(NOCT): 방사 조도 800W/m², AM 1.5, 주위온도 20℃, 풍속1m/s

열 특성

작동 온도 범위

-40~85 °C

온도 계수(Pmax)

-0.36 %/°C

온도 계수(Voc)

-0.27 %/°C

온도 계수(Isc)

0.04 %/°C

시스템 통합 파라미터

최대 시스템 전압

1500 V

퓨즈의 정격전류

20 A

기계적 특성

모듈 외형 (H/W/D)

2094x1038x35 mm

무게

24.5 kg

셀종류

PERC

설수량

144

유리 유형

저반사, 강화

유리의 두께

3.2 mm

프레임

양극산화 알루미늄

바이패스 다이오드 수

정션박스 보호등급

IP 68

커넥터 유형

MC4

케이블 단면도

4 mm²

커넥터 케이블 길이

300 mm

PDF

제품 사양서 다운받기

Projects

About US

RonmaSolar, one of the earliest manufacturers of solar panels in China, is mainly engaged in crystalline silicon solar cells, modules, pv system engineering, pv application products R&D, manufacturing, sales, technical support, EPC and after-sales service, etc.

We can offer Mono/Poly-crystalline Silicon PERC and N-Type TOPCON Solar Cells with efficiency up to 24%+. Also, we can customize 380-660W photovoltaic modules, including full/half-cutting cell modules, single/dual-glass modules, full black modules and other kinds of photovoltaic modules. Besides, we can provide customized solutions for global customers.

Our advantage as follows:

1.We have warehouses in Rotterdam, Dubai and other countries with enough stock for panels.

2.Ronma Solar's existing cell and module production capacity is 3GW each, and it is expected that in 2023, the cell production capacity will reach 14GW and the module production capacity will be 5GW+.

3.We have nearly 10 years of experience of PV, with the most advanced technology and the highest level of craftsmanship.

4.We have sales offices in India, Europe and others.

5.We have the most experienced engineering team, the strictest quality control team, and the professional sales team, which can provide the highest cost-effective, high efficiency solar modules, and the most perfect service.

6.RonmaSolar PV products have highly recognized by clients from China, India, The European, South America, Middle East and Africa, Southeast Asia etc.Our products have obtained CEC, TUV, BIS, CCC, CQC, CE, IEC and INMETRO certifications.

7.RonmaSolar components were successfully included in the list of the Ministry of Industry and Information Technology of the People's Republic of China. The list of top ten central SOE suppliers in China are: State Power Investment, China Huaneng, China Anneng, China Power Construction, China Energy Engineering Group, China Metallurgical Corporation, China National Nuclear Corporation, China Minmetals Corporation, China Resources Power Holdings, and China Datang Corporation.
