Spirit Series NKM-144 530-550 Bifacial

Name: Spirit Series NKM-144 530-550 Bifacial
Brand: Nuuko Power
SKU: 50946
Price: 0.15000 USD
Availability: InStock

Nuuko Power Co., Ltd.

가격:

최저가격 ₩204 / Wp

유형:	양면형
공율범위:	530 ~ 550 Wp
지역:	중국

참고: 귀하의 문의가 Nuuko Power Co., Ltd.로 직접 발송이 될 것입니다.

제품 설명:

-Hign module conversion efficiency (up to 21.3%)

-Excellent weak light performance

-Nuuko current sorting process

-Extended wind (up to 3800 Pa)and snow load tests(up to 5400 Pa)

-Lower operating temperature

-Withstanding harsh enviroment

제품 정보
회사 프로필

제품특성

모델명

NKM530M-144

NKM535M-144

NKM540M-144

NKM545M-144

NKM550M-144

보증

제품보증연한

12 년

출력 보증

25년 동안 84.8% 이상의 효율

전기적 특성 (STC)

최대출력(Pmax)

530 Wp

535 Wp

540 Wp

545 Wp

550 Wp

최대전압(Vmpp)

41.4 V

41.6 V

41.8 V

41.9 V

42.1 V

최대전류(Impp)

12.81 A

12.87 A

12.94 A

13.02 A

13.08 A

개방전압(Voc)

49.2 V

49.4 V

49.5 V

49.7 V

49.9 V

단락전류(Isc)

13.76 A

13.83 A

13.89 A

13.96 A

14.01 A

모듈 호률

20.5 %

20.7 %

20.9 %

21.1 %

21.3 %

출력 허용오차 (+)

+ 1 %

표준 테스트 조건(STC): AM 1.5, 방사조도 1000W/m², 셀오돈 25°C

전기적 특성 (NOCT)

최대출력(Pmax)

401 Wp

404 Wp

408 Wp

412 Wp

415 Wp

최대전압(Vmpp)

38.2 V

38.4 V

38.6 V

38.7 V

38.9 V

최대전류(Impp)

10.47 A

10.53 A

10.58 A

10.63 A

10.67 A

개방전압(Voc)

46.3 V

46.4 V

46.5 V

46.7 V

46.9 V

단락전류(Isc)

11.02 A

11.08 A

11.13 A

11.18 A

11.22 A

온도

43±2 °C

공칭 작동 셀 온도(NOCT): 방사 조도 800W/m², AM 1.5, 주위온도 20℃, 풍속1m/s

열 특성

작동 온도 범위

-40~85 °C

온도 계수(Pmax)

-0.36 %/°C

온도 계수(Voc)

-0.26 %/°C

온도 계수(Isc)

0.043 %/°C

시스템 통합 파라미터

최대 시스템 전압

1500 V

퓨즈의 정격전류

30 A

기계적 특성

모듈 외형 (H/W/D)

2279x1134x35 mm

무게

32.2 kg

셀종류

양면형

설수량

144

유리 유형

저반사, 강화

유리의 두께

2 mm

프레임

양극 처리 된 알루미늄 합금

바이패스 다이오드 수

정션박스 보호등급

IP 68

커넥터 유형

MC4

케이블 단면도

4 mm²

PDF

제품 사양서 다운받기

Product Details

Our Company

Projects

Nuuko Power Co., Ltd.

: Click to show company phone
: www.nuukopower.com
: 중국
: No. 16 Building, Xiangcheng Road, Feidong Economic Development zone, Hefei city, China.

직원수: 300

참고: 귀하의 문의가 Nuuko Power Co., Ltd.로 직접 발송이 될 것입니다.

결정실리콘

생산량 (MW)/: MWp

단결정, 다결정

공율범위(Wp): 350-670

유용한 연락처

Aber

Vincent

Alice

Michael

Amy

Camellia

Anny

Chris

Iris

회사 설명

Nuuko Power has nearly 10 years of experience in the photovoltaic industry, it has an automated production workshop. Up to now, it has provided solar modules, system solutions, and customized services for more than 40 countries around the world.

Nuuko has created a "closed-loop" development model of solar module R&D and production, and distribution cooperation. Its business also covers power station development and investment, solar system integration and sales, etc. Products have been approved by international certifications like TUV, CE, CEC, INMETRO, RETIE, etc., and domestic certifications like CQC, ISO9001, ISO14001, OHSAS18001, etc.

With patents for inventions and utility models, it is a national science and technology enterprise. Committed to becoming the world's leading new energy company, creating a sustainable future through clean solar energy.

제품 동영상

Star Series NKM-144M6 440-460 솔라패널

Spirit Series NKM-144M10 535-555 솔라패널

제품

Our Company

Experienced R&D Innovation System

The group brings together top experts and talents from home and abroad in the fields of silicon wafers, solar cells, and solar panels and has hundreds of sets of state-of-the-art development software, instruments, and equipment. Nuuko strengthens cooperation with various research institutes at home and abroad, builds platforms for enterprises, universities, and research institutes, and has cooperated with a number of universities and research institutions to develop research in the field of materials.

Scientific Researcher Management and Incentive System

The group conducts technical seminars, establishes a professional title evaluation system, forms a scientific mechanism of talent training, exchange, learning, and improvement, and continuously enhances the professional skills of R&D talents in order to accumulate technological innovation strength for enterprises and establish a sustainable mechanism for talent development.

Strict Quality Management System

Nuuko stringently selects raw materials that meet the requirements of ISO IEC 17024.
To ensure product safety and reliability all products need pass IEC 61215 and IEC 61730 test certification.

Manufacturing complies with international quality and environmental management standards ISO 9001, QC080000, ISO 14001, and OHSAS 18000.
